Oxford University Press Text Capture Instructions



Grouped lines

Where two or more lines or items in a list are grouped together e.g. with a brace to a label, use the group element to contain both the items and the label.

group[groupLabel and groupItem]

Labels can be on either or both sides of the group, as defined by the labelposition.

If there are labels on both sides, add a position attribute to both groupLabel elements.

If there is only a brace grouping the lines together, without a label, use a self-closing groupLabel/.

Capture complex layout using grouped lines within Meaningful Columnar Text.

Print

media/535195_image52.png

XML


<group labelPosition="right">
<groupLabel>‘two noble Venetians’</groupLabel>
<groupItem>
<sc>lodovico</sc>
</groupItem>
<groupItem>
<sc>gratiano</sc>, brother to Brabantio</groupItem>
</group>

Print

XML


<group labelPosition="both">
<groupLabel position="left">The</groupLabel>
<groupLabel position="right">Object of all Delight;</groupLabel>
<groupItem>Ineffable,</groupItem>
<groupItem>Fathomless,</groupItem>
<groupItem>Eternal,</groupItem>
</group>

Print

XML


<line>
<milestone unit="line" num="7" id="actrade-9780199692347-milestone-3814"/>Did now in
numerous Shoals themselves display,</line>
<line>
<milestone unit="line" num="8" id="actrade-9780199692347-milestone-3815"/>And made
appear a Fifth more glorious Day,</line>
<group labelPosition="right">
<groupLabel/>
<groupItem>
<milestone unit="line" num="9" id="actrade-9780199692347-milestone-3816"/>Fairer
than any that had gone before.</groupItem>
<groupItem>
<milestone unit="line" num="10" id="actrade-9780199692347-milestone-3817"/>Oh!
who can God sufficiently adore,</groupItem>
<groupItem>
<milestone unit="line" num="11" id="actrade-9780199692347-milestone-3818"/>Who
this Day gen'rated so rich a Store?</groupItem>
</group>
<line>
<milestone unit="line" num="12" id="actrade-9780199692347-milestone-3819"/>A Day most
fair! when his Almighty Skill</line>
<line>
<milestone unit="line" num="13" id="actrade-9780199692347-milestone-3820"/>Did all the
Seas, and Lakes, and Rivers fill.</line>
